Free Modern Geometric Stacked Building Facade DXF & SVG Vector File
This modern architectural line drawing features a striking stacked facade with geometric proportions across three distinct levels and irregularly sized windows. The contemporary design showcases a deconstructed form ideal for architectural visualization, laser cutting, and CNC routing projects. Download the DXF & SVG vector file to create architectural models, wall art, or custom fabrication pieces.
Includes DXF, SVG and PDF formats
100% free for personal and commercial use. No attribution required. Sign in with your email to download.
Works with Glowforge, xTool, LightBurn, AutoCAD, Fusion 360, Inkscape and more.
Generate a custom drawing
Upload any image and get a production-ready vector file in minutes
Create Your Own Drawing for FreeCompatible Machines, Software & Materials
This Modern Geometric Stacked Building Facade DXF and SVG file is production-ready and compatible with all major CNC machines including CO2 laser cutters, diode lasers, fiber lasers, CNC routers, plasma cutters, waterjet cutters, vinyl cutters, and cutter plotters. Works with Glowforge, xTool, Epilog, OMTech, Thunder Laser, Boss Laser, Ortur, Atomstack, Snapmaker, Cricut, Silhouette, Roland, Graphtec, Hypertherm, PrimeWeld, and all other machines that accept standard DXF or SVG vector formats.
Compatible Software
Adobe Illustrator, CorelDRAW, Inkscape, AutoCAD, Fusion 360, SketchUp, Rhino, LightBurn, VCarve Pro, Aspire, Carbide Create, Easel, LaserGRBL, Mach 4, LinuxCNC, SheetCam, PlasmaCAM, CamBam, Cricut Design Space, Silhouette Studio, Sure Cuts A Lot, and most other vector editing or CAM software.
Suitable Materials
Wood, plywood, MDF, bamboo, cork, acrylic, foam, metal, mild steel, stainless steel, aluminum, brass, copper, leather, paper, cardstock, cardboard, vinyl, fabric, and most other materials supported by your cutting machine. Files are fully editable and can be scaled to any dimension to suit your project.
