Free Tokyo Stacked House Facade DXF & SVG
A narrow multi-story urban house in Tokyo, notable for its stacked geometric volumes and exposed exterior staircase zigzagging across the facade. The line work captures the angular stair geometry, recessed window openings at each floor level, and the interlocking box-like volumes rising to a top-floor skylight canopy. DXF, SVG, and PDF formats are included, suited to architectural scale models, facade and elevation studies, and architectural drafting reference.
Includes DXF, SVG and PDF formats
100% free for personal and commercial use. No attribution required. Sign in with your email to download.
Works with Glowforge, xTool, LightBurn, AutoCAD, Fusion 360, Inkscape and more.
Generate a custom drawing for free
Upload any image and get a production-ready vector file in minutes
Compatible Machines, Software & Materials
This Red Stacked House Tokyo Facade DXF and SVG file is production-ready and compatible with all major CNC machines including CO2 laser cutters, diode lasers, fiber lasers, CNC routers, plasma cutters, waterjet cutters, vinyl cutters, and cutter plotters. Works with Glowforge, xTool, Epilog, OMTech, Thunder Laser, Boss Laser, Ortur, Atomstack, Snapmaker, Cricut, Silhouette, Roland, Graphtec, Hypertherm, PrimeWeld, and all other machines that accept standard DXF or SVG vector formats.
Compatible Software
Adobe Illustrator, CorelDRAW, Inkscape, AutoCAD, Fusion 360, SketchUp, Rhino, LightBurn, VCarve Pro, Aspire, Carbide Create, Easel, LaserGRBL, Mach 4, LinuxCNC, SheetCam, PlasmaCAM, CamBam, Cricut Design Space, Silhouette Studio, Sure Cuts A Lot, and most other vector editing or CAM software.
Suitable Materials
Wood, plywood, MDF, bamboo, cork, acrylic, foam, metal, mild steel, stainless steel, aluminum, brass, copper, leather, paper, cardstock, cardboard, vinyl, fabric, and most other materials supported by your cutting machine. Files are fully editable and can be scaled to any dimension to suit your project.
